Gallery

Gallery is a React component for creating dynamic image and video galleries in 2D and 3D.

Lay items out as a list, grid, barrel, coverflow, helix, ring, sphere or card stack, then drag, scroll or key through them.

Change the arrangement, open an item or add and remove items, and every change animates smoothly from wherever the gallery is.

<Gallery arrange={barrel()} aria-label="Collection">
  <Gallery.Image src="/a.jpg" alt="Runner" width={1200} height={1600} />
  <Gallery.Video src="/b.mp4" poster="/b.jpg" alt="Shoe rotating" />
</Gallery>

Features

• Eight arrangements: list, grid, barrel, coverflow, helix, ring, sphere and stack, or write your own with defineGalleryArrangement.

• Smooth everything: Arrangement swaps, opening an item, adding and removing items all blend from the current pose, with springs and stagger.

• Inputs: Drag with momentum, wheel and keyboard navigation out the box, with snapping and infinite looping.

• Detail views: Open an item into its own box with a thumbnail strip, or reveal a panel around it. Higher-res assets are loaded automatically.

• Velocity effects: tilt and ripple modifiers link items to the gallery's speed.

• Shaders: Draw items with WebGPU through shaders like depthOfField and reflection. Without WebGPU, the DOM draws them as normal.

• Accessible: Uses the correct ARIA tags, respects reduced motion and supports keyboard navigation.

• Performant: All items animated with transform, and only visible media loads and plays.

Install

First, install Motion UI in your project. You need to be a Motion+ member to generate an access token.

Usage

Import

Import Gallery from "motion-plus/gallery":

import { Gallery } from "motion-plus/gallery"

Arrangements, modifiers and presence presets are separate imports, so only the ones you use are bundled:

import { Gallery, barrel, tilt } from "motion-plus/gallery"

Items

Gallery accepts three kinds of item as children.

• Gallery.Image renders an img. alt is required. Use "" for decorative images.

• Gallery.Video renders a video. alt is required and is applied as aria-label.

• Gallery.Item renders an li with any content inside.

<Gallery aria-label="Studio work">
  <Gallery.Image
    src="/photo.jpg"
    alt="Dancer mid-turn"
    width={800}
    height={1000}
  />
  <Gallery.Video src="/clip.mp4" poster="/clip.jpg" alt="Product turntable" />
  <Gallery.Item>
    <h2>Any content</h2>
  </Gallery.Item>
</Gallery>

Each item can take a value. This is its identity for active, selected, callbacks and hooks. Without one, items are identified by their index.

<Gallery.Image value="runner" src="/runner.jpg" alt="Runner" />

Size

Give the gallery a size with CSS, and its items a size with the --gallery-item-width and --gallery-item-height CSS variables. Items default to 240px by 320px.

.gallery {
  height: 100vh;
}

.gallery [data-gallery-item] {
  --gallery-item-width: 300px;
  --gallery-item-height: 400px;
}

The engine owns each item's position, size, transform and opacity. Everything else, like border-radius, background and filter, is yours to style.

Arrangements

Pass an arrangement to arrange. The default is list().

<Gallery arrange={helix({ itemsPerTurn: 8 })} />

Change arrange at any time and the gallery animates into the new shape.

list

Items along a straight track: horizontal, vertical (axis="y") or diagonal (angle).

<Gallery arrange={list({ angle: -30, curl: 20, depth: 40, wave: 30 })} />

grid

An infinite, pannable plane. When looping, which is the default, it's tiled with clones so its edge is never visible.

<Gallery arrange={grid({ columns: 6, fill: "offset", rotateX: 20, bulge: 120 })} />

barrel

Items around a cylinder. axis="y" gives a vertical barrel. A barrel always loops.

<Gallery arrange={barrel({ radius: 600, rotateX: -12 })} axis="y" />

coverflow

The classic: a flat focused item with angled, overlapping neighbours. Coverflow spaces items with its own options, so it ignores gap.

<Gallery arrange={coverflow({ turn: 45, spread: 0.25, depth: 0.6, centerSpacing: 0.9 })} />

helix

A spiral. The default axis is "y", which gives a vertical spiral. axis="x" gives a horizontal corkscrew.

<Gallery arrange={helix({ radius: 500, itemsPerTurn: 12, pitch: 48 })} />

ring

Items around a flat circle, like a dial. An arc under 360 fans them out.

<Gallery arrange={ring({ arc: 120, upright: true, flip: true, rotateX: 10 })} />

sphere

Items on a sphere. Dragging spins it both ways. A sphere always loops.

<Gallery arrange={sphere({ radius: 700, gap: 12, face: "outward" })} />

stack

A deck of cards. Swipe the top card away to reveal the next. A stack spaces items with its own options, so it ignores gap.

<Gallery arrange={stack({ peek: 20, depth: 60, visible: 3 })} />

Every numeric arrangement option, apart from grid's columns, also accepts a motion value, so it can be animated or linked to scroll without a re-render.

const rotateX = useMotionValue(-8)

return <Gallery arrange={barrel({ rotateX })} />
